LSG-20
2.0W 120V Indoor / Outdoor LED Strip
Heading #2 | |
|---|---|
POWER CONSUMPTION | 2W per Ft. |
LUMEN OUTPUT | 196 Lumens per Ft. |
CRI | 90+ |
DIMMING | ELV & TRIAC |
MAXIMUM RUN LENGTH | 150 Ft. |
CUTTABLE | Every 6.0 in (152.4mm) |
BINNING | 2-Step MacAdam Ellipse |
OPERATING VOLTAGE | 120V AC |
OPERATING TEMPERATURE | -22°F (-30°C) to +122°F (+50°C) |
RATING | Indoor(IP54) | Outdoor(IP67) |
LUMEN MAINTENANCE | 50,000 Hrs. |
SPEC SHEET
FEATURES
DIMENSIONS
